The Quadstick can be used both on PC (in controller or mouse mode) and on PS4. But it is possible to use adapters to play on all consoles.
Here you will find the different compatible techniques.
1/ QUADSTICK ON PS4
In the QMP configuration file: "Playstation Outputs"
Basic solution:
On the QMP application "Select Boot in PS4 Mode"
connect a PS4 controller to the rear USB input of the Quadstick
plug the quadstick into the USB input of the PS4
Solution with Cronus Max:
Turn on the PS4
Plug the Cronus Max into the USB input of the PS4
Either connect the Quadstick directly to the Cronus Max ("Partial crowwover" with disconnections every 7 minutes)
Either use a USB hub to connect both the Quadstick and a PS4 controller ("Full crossover" without interruptions)
Possibility of connecting a tupe Ultrastick analog joystick to the USB input of the Quadstick.
2/ QUADSTICK ON XBOX ONE OR SERIES S/X
In the QMP configuration file: "Xbox Outputs"
Warning: Xbox has blocked the use of Brook Converter.
With the Cronus Zen and an Xbox controller
Connect the Quadstick to the input at the bottom left of the converter
Connect an official Xbox controller to the input on the left of the converter
plug the Cronus converter into the Xbox USB input
Buy Cronus Zen : Adaptateur Cronus ZEN | Stealth-Gamer.com
With Cronus Max and an Xbox controller
Remove batteries from Xbox controller
Turn on the console
Plug the Cronus Max into the console's USB input
plug the Xbos controller into the Cronus Max (without turning it on)
unplug the controller
connect the Quadstick to the cronus Max input
Possibility of connecting an Ultrastick type analog joystick to the USB input of the Quadstick.
Using Xbox Adaptive Controller
in this case the quadstick will be able to control 8 buttons maximum
On this page you will find configuration examples:
Order here:
3/ QUADSTICK ON PC
In the QMP configuration file: "Xbox Outputs"
ATTENTION : on PC do not use the PS4 config but rather the XBOX config
example of Fortnite configuration file on PC by RockyNoHands:
RockyNoHands Fortnite XBox 360 for PC - Google Sheets
4/ QUADSTICK ON PS5
It's official, Sony has blocked the use of Cronus Zen on PS5. This system is in fact identified as a means of cheating due to its programming possibilities.
The official site announces the possibility of using it via Remote Play.
We recommend a configuration instead Remote Play (very good software: CHIAKI ) + Playability to connect your Quadstick and add additional controls. You will not need to purchase the Cronus Zen.
Follow our Remote Play installation guide:
Remote Play on PS5: our guide – HitClic
